| Basic Data | |
| manufacturers | NIO |
| level | medium car |
| energyjype | pure electric |
| time to market | 2021.12 |
| electric motor | Pure electric 490 horsepower |
| Pure electric cruising range (km) Ministry of Industry and Information Technology | 560 |
| Pure electric cruising range (km) CLTC | 560 |
| Charging time (hours) | Quick charge 0.6 hours |
| Quick charge capacity (%) | 10-80 |
| Maximum power (kW) | 360(490Ps) |
| Maximum torque (N・m) | 700 |
| gearbox | Electric vehicle single speed gearbox |
| Length x width x height .(mm). | 4790x1960x1499 |
| Body structure | 5 door 5 seat sedan |
| Maximum speed(km/h) | - |
| Official 100km acceleration time (s) | 4 |
| Power consumption per 100 kilometers fkWh/100km) | 16.9 |
| Electric energy equivalent fuel consumption(L/100km) | 1.73 |
| Vehicle Warranty Period | 3 years or 120,000 kilometers |
| First owner warranty period | 10-year unlimited mileage warranty (the liability exemption clause shall be subject to the official website) |
| Estimated total cost of maintenance for 60,000 kilometers | 856.0 yuan |
| body | |
| length (mm) | 4,790 |
| width (mm) | 1,960 |
| height (mm) | 1,499 |
| Wheelbase (mm) | 2,888 |
| Front track(mm) | 1,685 |
| Rear track(mm) | 1,685 |
| Body structure | Sedan |
| Number of doors (a) | 5 |
| Door opening method | side hinged door |
| Number of seats (pieces) | 5 |
| curb weightfkg) | 2,180 |
| Full load mass(kg) | 2,690 |
| Lug gage compartment volume (L) | - |
| Drag Coefficient (Cd) | 0.24 |
| electric motor | |
| Motor description | Pure electric 490 horsepower |
| motor type | Front induction/asynchronous rear permanent magnet/synchronous |
| Total motor power (kWl | 360 |
| Motor total horsepower .(Ps). | 490 |
| Motor total torque (N m) | 700 |
| Maximum power of the front motor (kW) | 150 |
| Front motor maximum | 280 |
| torque (N m) | |
| Maximum power of rear motor (kW) | 210 |
| Maximum torque of rear motor (N m) | 420 |
| Number of drive motors | dual motor |
| Motor layout | front + rear |
| Charging batteries | |
| Battery Type | Lithium iron phosphate battery + ternary lithium battery |
| Battery brand | CATL |
| Battery Pack Warranty | 10-year unlimited mileage warranty for the first owner (the liability exemption clause is subject to the official standard) |
| Battery capacity (kWh) | 75 |
| Battery energy density.(Wh/kg). | |
| Charging batteries | Quick charge 0.6 hours |
| • Fast charging port | |
| Fast charging interface location | left fuel tank |
| Slow charging interface location | - |
| Battery Temperature Management System | low temperature . heating |
| . liquid cooling | |
| one pedal mode | • Standard |
| Battery swap support | • Standard |
| Brand self-operated charging station | • Standard |
| VTOL mobile power station function | - |
| Charging pile | - |
| gearbox | |
| Gearbox Description | Electric vehicle single speed gearbox |
| Gears | 1 |
| gearbox type | fixed gear ratio gearbox |
| Chassis/Steering | |
| drive mode | Dual motor four-wheel drive |
| 4WD type | Electric four-wheel drive |
| Front suspension | Multi-link independent suspension |
| rear suspension | Multi-link independent suspension |
| steering type | electric assist |
| Body structure | load-bearing |
| Wheels/brakes | |
| Front Brake Type | Ventilated Disc |
| rear brake type | Ventilated Disc |
| Parking Brake Type | electronic parking |
| Front tire size | 245/45 R19 |
| Rear tire size | 245/45 R19 |
| Spare tire specifications | unknown |
| active safety | |
| ABS anti-lock brake | Standard |
| Braking force distribution (EBD/CBC. etc.) | Standard |
| Brake Assist (EBA/BA etc.) | Standard |
| Traction Control (TCS/ASR etc). | Standard |
| Body stabilization system (ESP/DSC. etc.) | Standard |
| lane departure warning | |
| forward collision warning | |
| Active Safety Warning System | rear collision warning |
| Reversing vehicle side warning | |
| DOW open door warning | |
| active braking | Standard |
| Parallel Assist | Standard |
| Lane Keeping Assist | Standard |
| lane centering | Standard |
| Fatigue Driving Tips | Standard |
| Active DMS Fatigue Detection | • Standard |
| In-vehicle vital sign detection | - |
| Road Traffic Sign Recognition | • Standard |
| Signal light recognition | • Standard |
| night vision system | - |
| passive safety | |
| front airbag | • driver's seat |
| • co-pilot | |
| side airbag | • front row |
| side curtain airbags | • Standard |
| front knee airbag | - |
| central airbag | • front row |
| Seat belt not fastened reminder | • Standard |
| tire pressure monitoring system | • tire pressure display |
| Child seat interface (ISOFIX) | • Standard |
| passive pedestrian protection | - |
| safety tire | - |
| Assist/Control Configuration • Standard 。Optional | |
| parking radar | • forward |
| • rear | |
| Reminder of the vehicle ahead | • Standard |
| • Reverse image | |
| Driving Assistance Video | 360° panoramic image |
| transparent image | |
| cruise control | |
| cruise system | adaptive cruise |
| Full speed adaptive cruise | |
| Automatic Lane Change Assist | Standard |
| Ramp automatic exit (entry) | Standard |
| Assisted driving level | L2 level |
| L3 level | |
| automatic parking | Standard |
| Tracking and reversing | Standard |
| memory parking | Standard |
| Automatic parking (AUTOHOLD) | Standard |
| Hill Assist (HAC) | Standard icon |
| Hill descent (HDC) | - |
| Variable Suspension Adjustment | - |
| air suspension | - |
| Electromagnetic induction suspension | - |
| Variable Steering Ratio System | - |
| Front axle limited slip mode | - |
| Rear axle limited slip mode | - |
| Center differential lock function | - |
| Integral Active Steering | - |
| • sports | |
| driving mode selection | • ECO |
| • the snow | |
| • standard comfort | |
| Brake Energy Recovery System | • Standard |
| Low-speed driving warning sound | • Standard |
| external configuration • | |
| sl^dighttype | Panoramic sunroof • cannot be opened |
| light-sensitive canopy | - |
| roof rack | - |
| sporty appearance kit | - |
| electric spoiler | - |
| Active closed air intake grille | - |
| Aluminum alloy wheels | • Standard |
| Frameless design doors | • Standard |
| hidden door handle | • Standard |
| tow hook | - |
| internal configuration | |
| steering wheel material | • Genuine Leather |
| steering wheel acjjustment | up and down + front and back |
| Electric steering wheel adjustment | • Standard |
| • multifunction control | |
| steering wheel function | • memory |
| 。heating | |
| trip computer screen | • color |
| LCD instrument style | • Full LCD |
| LCD Meter Dimensions (inches) | • 10.2 |
| LCD instrument resolution | 1920x532 |
| LCD instrument screen pixel density (PPI) | • 158 |
| Comfort/Anti-Theft Configuration | |
| Electric suction door | Standard |
| electric tailgate | Standard icon |
| Inductive tailgate | Standard icon |
| Electric tailgate position memory | Standard |
| Central locking in the car | Standard |
| smart remote key | |
| NFC/RFID key | |
| Key fob type | mobile phone bluetooth key |
| UWB digital key | |
| keyless entry | whole car icon |
| keyless start | Standard icon |
| remote start | Standard |
| remote control vehicle | - |
| vehicle call function | 。Optional |
| Head-Up Display (HUD) | - |
| Built-in driving recorder | • Standard |
| Original ETC | • Standard |
| Active Noise Cancellation | - |
| mobile phone wireless charging | • Standard icon |
| Mobile phone wireless charging maximum power (W) | 15 |
| 110V/220V/230V power socket | - |
| Lug gage compartment 12V power interface | • Standard |
| seat configuration | |
| seat material | • imitation leather |
| 。Genuine Leather | |
| seat leather style | 。Nappa leather |
| sporty seat | • Standard |
| Second row individual seats | - |
| Electric Seat Adjustment | • driver's seat |
| • co-pilot | |
| • move back and forth | |
| Overall adjustment of the driver's seat | • backrest angle |
| • height adjustment | |
| • headrest | |
| Partial adjustment of the driver's seat | • waist |
| 。leg rest | |
| Overall adjustment of passenger seat | • move back and forth |
| • height adjustment | |
| • backrest angle | |
| • headrest | |
| Partial adjustment of passenger seat | • waist 。leg rest |
| Overall adjustment of the second row of seats | - |
| Second row seat partial adjustment | - |
| • heating | |
| front seat function | 。ventilation |
| • memory | |
| 。massage | |
| Second row seat functions | 。heating |
| boss key | - |
| front/rear armrest | • front row |
| • back row | |
| rear cup holder | • Standard |
| Heated/cooled cup holder | - |
| Rear seat down ratio | • Proportion down |
| Second row of small table boards | - |
| Smart Internet • Standard 。Optional - none | |
| Central control screen size (inches) | • 12.8 |
| Center console color screen resolution | 1728x1888 |
| Center console color screen pixel density (PPI) | • 200 |
| Touch screen vibration feedback | - |
| screen layout | Traditional dual-screen • layout |
| GPS navigation system | • Standard |
| AR real-world navigation | - |
| Navigation traffic information display | • Standard |
| roadside assistance service | • Standard icon |
| Bluetooth/Car Phone | • Standard |
| Mobile Internet Mapping | - |
| Internet of Vehicles | • Standard |
| 4G/5G network | • 5G |
| OTA upgrade | • Standard |
| face recognition | - |
| Fingerprint recognition | - |
| voiceprint recognition | - |
| emotion recognition | - |
| Voice recognition control system | • Standard |
| Voice free wake-up function | • Standard |
| • main driver | |
| Voice sub-area wake-up recognition function | • co-pilot |
| • second row | |
| Continuous Speech Recognition | • Standard |
| see can say | • Standard |
| voice assistant wake word | Hi NOMI |
| gesture control | - |
| Wi-Fi hotspot | • Standard |
| Media entertainment • Standard 。Optional - none | |
| Multi-finger flying screen control | - |
| app Store | • Standard |
| multimedia interface | • USB/Type-C |
| Number of USB/Type-C | • 2 front row |
| ports | • 1 back row |
| USB/7ype-C maximum | Front row 60W |
| charging power | Rear row 60W |
| Car TV | - |
| rear LCD screen | - |
| simulated sound waves | • Standard |
| audio brand | - |
| Number of speakers (units) | • twenty three |
| rear multimedia controls | - |
| lighting configuration • Standard 。Optional - none | |
| Low beam lights | • led |
| High beam | • led |
| daytime running lights | • Standard |
| Adaptive far and near light | • Standard |
| automatic headlights | • Standard |
| turn signal lamp | • Standard |
| Front fog lights | • Standard |
| Penetrating headlights | - |
| through tail lights | • Standard |
| Headlight Adaptive Steering (AFS) | - |
| headlight height adjustment | • Standard |
| headlight cleaning function | - |
| interior ambient light | • 256 colors |
| Active Ambient Mood Lighting | - |
| Lighting Features | - |
| Delayed headlight off | • Standard |
| Headlight rain and fog mode | - |
| glass/mirror • Standard | 。Optional - none |
| electric windows | • front row |
| • back row | |
| One-button window lift | • whole car |
| Window anti-pinch function | • Standard |
| electric • icon adjustment | |
| • heating | |
| • electric folding | |
| Exterior mirror function | • memory |
| Automatic downturn • when reversing | |
| Automatic folding when . locking the car | |
| • Automatic anti-glare | |
| Interior rearview mirror function | • Automatic anti-glare |
| vanity mirror | Main driving position + . lighting Passenger seat + lighting |
| rear privacy glass | • Standard |
| interior sunshade | - |
| Rain Sensing Wipers | • Standard |
| rear wiper | - |
| Multi-layer soundproof glass | - |
| Front windshield electric | |
| heating | |
| heated water nozzle | - |
| air conditioner/refrigerator | |
| Air Conditioning Control | • automatic |
| Mode | |
| Rear independent air conditioner | - |
| rear air outlet | • Standard |
| Temperature zone control | Dual Zone Air • Conditioning |
| Car air purifier | • Standard |
| In-car PM2.5 filter | • Standard |
| HEPA filter | - |
| negative ion generator | 。Optional |
| car fragrance device | 。Optional |
| car refrigerator | - |
| Intelligent configuration | |
| Assisted driving operating system | • NAD |
| Assisted driving chip | • NVIDIA DRIVE Orin |
| Assisted Driving Chip Computing Power (TOPS) | • 1016 |
| Vehicle Intelligent System | • Banyan |
| Vehicle Smart Chip | Qualcomm Snapdragon * 8155 |
| In-vehicle system memory (GB) | • 16 |
| In-vehicle system storage (GB) | • 256 . digital key • vehicle monitoring • remote control |
| Mobile App remote control | • service appointment • charge management Smart car search assistant |
| heat pump management system | • Standard |
| Number of cameras outside the car (units) | • 11 |
| Number of cameras in the car (units) | • 1 |
| Ultrasonic radar quantity (unit) | • 12 |
| Number of millimeter wave radars (units) | • 5 |
| Number of lidars (units) | • 1 |
| Sub-meter high-precision positioning system | • Standard |
| HD map | • Standard |
| Sentry (clairvoyance) mode | • Standard |
| V2X communication | • Standard |
| optional package • Standard 。Optional - none | |
| Customized options | Optional appearance, interior; wheels, brakes 3 optional packages |
| Microfiber microfiber fleece canopy | 。Optional 6500 yuan |
| NOMI vehicle artificial intelligence system | NOMI Halo NOMI Mate 2.0 |
| 。Optional 4900 yuan | |
| Nappa Premium Interior Package | Premium Nappa perforated leather seats Premium Nappa leather upholstery covered with Microfiber fleece headliner |
| 。Optional 22500 yuan | |
| Appearance Kit - Moon Theme | 。Optional 4500 yuan |
| Airglow orange calipers | 。Optional 3500 yuan |
| Appropriate package | Steering wheel heating Front seat 14-way electric adjustment (including 4-way lumbar support adjustment and seat cushion extension) Front seat ventilation Front seat |
| massage Second row seat heating Intelligent fragrance system Negative ion generator | |
| 。Optional 9500 yuan | |
| Featured configuration | |
| AR/VR panoramic immersive experience interface | • Standard |
