| Basic Data | |
| manufacturers | NIO |
| level | Medium and large SUV |
| energyjype | pure electric |
| time to market | 2022.12 |
| electric motor | Pure electric 653 horsepower |
| Pure electric cruising range (km) Ministry of Industry and Information Technology | 465 |
| Pure electric cruising range (km) CLTC | 465 |
| Charging time (hours) | - |
| Quick charge capacity (%) | 10-80 |
| Maximum power (kW) | 480(653Ps) |
| Maximum torque (N・m) | 850 |
| gearbox | Electric vehicle single speed gearbox |
| Length x width x height .(mm). | 5099x1989x1750 |
| Body structure | 5-door 6-seat SUV |
| Maximum speed(km/h) | 200 |
| Official 100km acceleration time (s) | 4.1 |
| Power consumption per 100 kilometers fkWh/100km) | 17.6 |
| 10-year unlimited mileage warranty for the first | |
| Vehicle Warranty Period | owner (the liability exemption clause is subject to the official standard) |
| First owner warranty period | 10-year unlimited mileage warranty (the liability exemption clause shall be subject to the official website) |
| body | |
| length (mm) | 5,099 |
| width (mm) | 1,989 |
| height (mm) | 1,750 |
| Wheelbase (mm) | 3,070 |
| Front track(mm) | 1,692 |
| Rear track(mm) | 1,702 |
| Body structure | SUV |
| Number of doors (a) | 5 |
| Door opening method | side hinged door |
| Number of seats (pieces) | 6 |
| curb weight(kg) | - |
| Full load mass(kg) | 3,190 |
| Lug gage compartment volume (L) | 235-552 |
| Drag Coefficient (Cd) | 0.25 |
| electric motor | |
| Motor description | Pure electric 653 horsepower |
| motor type | Front permanent magnet/synchronous rear AC/asynchronous |
| Total motor power (kWl | 480 |
| Motor total horsepower .(Ps). | 653 |
| Motor total torque (N m) | 850 |
| Maximum power of the front motor (kW) | 180 |
| Front motor maximum | 350 |
| torque (N m) | |
| Maximum power of rear motor (kW) | 300 |
| Maximum torque of rear motor (N m) | 500 |
| Number of drive motors | dual motor |
| Motor layout | front + rear |
| Charging batteries | |
| Battery Type | Lithium iron phosphate battery + ternary lithium battery |
| Battery brand | Jiangsu Times |
| Battery Pack Warranty | Unlimited years/mileage for the first owner |
| Battery capacity (kWh) | 75 |
| Battery energy density | |
| .(WhZkg). | 142.1 |
| Charging batteries | • Fast charging port |
| Fast charging interface location | right fender |
| Slow charging interface location | - |
| Battery Temperature Management System | low temperature • heating |
| • liquid cooling | |
| one pedal mode | • Standard |
| Battery swap support | • Standard |
| Brand self-operated charging station | • Standard |
| VTOL mobile power station function | • Standard |
| Charging pile | - |
| gearbox | |
| Gearbox Description | Electric vehicle single speed gearbox |
| Gears | 1 |
| gearbox type | fixed gear ratio gearbox |
| Chassis/Steering | |
| drive mode | Dual motor four-wheel drive |
| 4WD type | Electric four-wheel drive |
| Front suspension | Double wishbone independent suspension |
| rear suspension | Multi-link independent suspension |
| steering type | electric assist |
| Body structure | load-bearing |
| Wheels/brakes | |
| Front Brake Type | Ventilated Disc |
| rear brake type | Ventilated Disc |
| Parking Brake Type | electronic parking |
| Front tire size | 255/50 R20 |
| Rear tire size | 255/50 R20 |
| Spare tire specifications | - |
| Spare tire placement | - |
| active safety | |
| ABS anti-lock brake | Standard |
| Braking force distribution (EBD/CBC. etc.) | Standard |
| Brake Assist (EBA/BA etc.) | Standard |
| Traction Control (TCS/ASR etc). | Standard |
| Body stabilization system (ESP/DSC. etc.) | Standard |
| lane departure warning | |
| forward collision warning | |
| Active Safety Warning System | rear collision warning |
| Reversing vehicle side warning | |
| DOW open door warning | |
| active braking | Standard |
| Parallel Assist | Standard |
| Lane Keeping Assist | Standard |
| lane centering | Standard |
| Fatigue Driving Tips | Standard |
| Active DMS Fatigue Detection | Standard |
| In-vehicle vital sign detection | - |
| Road Traffic Sign Recognition | • Standard |
| Signal light recognition | - |
| night vision system | - |
| passive safety | |
| front airbag | • driver's seat |
| • co-pilot | |
| side airbag | • front row |
| side curtain airbags | • Standard |
| front knee airbag | - |
| central airbag | • front row |
| Seat belt not fastened reminder | • Standard |
| tire pressure monitoring system | • tire pressure display |
| Child seat interface (ISOFIX) | • Standard |
| passive pedestrian protection | - |
| safety tire | |
| Assist/Control Configuration | |
| parking radar | . forward |
| • rear | |
| Reminder of the vehicle ahead | • Standard |
| • Reverse image | |
| Driving Assistance Video | • 360° panoramic image |
| • transparent image | |
| • cruise control | |
| cruise system | • adaptive cruise |
| Full speed adaptive • cruise | |
| Automatic Lane Change Assist | • Standard |
| Ramp automatic exit (entry) | 。Optional |
| Assisted driving level | • L2 level |
| 。L3 level | |
| automatic parking | • Standard |
| Tracking and reversing | - |
| memory parking | - |
| Automatic parking (AUTOHOLD) | • Standard |
| Hill Assist (HAC) | • Standard icon |
| Hill descent (HDC) | • Standard icon |
| Variable Suspension Adjustment | Soft and hard + high and low |
| air suspension | • Standard |
| Electromagnetic induction suspension | - |
| Variable Steering Ratio System | - |
| Front axle limited slip mode | - |
| Rear axle limited slip mode | - |
| Center differential lock function | - |
| Low-speed four-wheel drive | - |
| Integral Active Steering | - |
| • sports | |
| driving mode selection | • ECO |
| • the snow | |
| • personalise | |
| • standard comfort | |
| Brake Energy Recovery System | • Standard |
| Low-speed driving warning sound | • Standard |
| external configuration | |
| sk/lighttype | Openable panoramic • sunroof |
| light-sensitive canopy | - |
| roof rack | 。Optional 3000 yuan |
| sporty appearance kit | - |
| electric spoiler | - |
| Active closed air intake grille | • Standard |
| Aluminum alloy wheels | • Standard |
| side pedal | - |
| Frameless design doors | - |
| hidden door handle | • Standard |
| tow hook | 。Optional |
| internal configuration | |
| steering wheel material | • leather |
| 。Genuine Leather | |
| steering wheel adjustment | up and down + front • and back |
| Electric steering wheel adjustment | • Standard |
| • multifunction control | |
| steering wheel function | • memory |
| • heating | |
| trip computer screen | • color |
| LCD instrument style | • Full LCD |
| LCD Meter Dimensions (inches) | • 10.2 |
| Comfort/Anti-Theft Configuration | |
| Electric suction door | Standard |
| electric tailgate | Standard icon |
| Inductive tailgate | Standard icon |
| Electric tailgate position memory | Standard |
| Central locking in the car | Standard |
| smart remote key | |
| Key fob type | mobile phone bluetooth key |
| NFC/RFID key | |
| UWB digital key | |
| keyless entry | whole car icon |
| keyless start | Standard icon |
| remote start | Standard |
| remote control vehicle | 。Optional |
| vehicle call function | 。Optional |
| Head-Up Display (HUD) | • Standard |
| Augmented Reality Head-Up Display (AR-HUD) | • Standard |
| Built-in driving recorder | • Standard |
| Original ETC | • Standard |
| Active Noise Cancellation | - |
| mobile phone wireless charging | • Standard icon |
| Mobile phone wireless charging maximum power (W) | 40 |
| 110V/220V/230V power socket | - |
| Lug gage compartment 12V power interface | • Standard |
| seat configuration | |
| seat material | • imitation leather |
| 。Genuine Leather | |
| sporty seat | - |
| seat layout | 2+2+2 |
| Second row individual seats | Standard |
| third row seats | 2 seats |
| driver's seat | |
| Electric Seat Adjustment | co-pilot |
| second row | |
| move back and forth | |
| Overall adjustment of the driver's seat | backrest angle |
| height adjustment | |
| headrest | |
| Partial adjustment of the driver's seat | waist |
| leg rest | |
| move back and forth | |
| Overall adjustment of passenger seat | height adjustment backrest angle |
| headrest | |
| Partial adjustment of passenger seat | waist leg rest |
| Overall adjustment of the second row of seats | move back and forth |
| Backrest angle adjustment | |
| Second row seat partial | leg rest |
| adjustment | waist |
| heating | |
| front seat function | ventilation |
| memory | |
| massage | |
| heating | |
| Second row seat | memory |
| functions | ventilation |
| massage | |
| Third row seat function | heating |
| boss key | |
| front/rear armrest | front row |
| back row | |
| rear cup holder | Standard |
| Heated/cooled cup holder | - |
| Rear seat down ratio | • 50:50 |
| Rear seat electric down | • Standard |
| Second row of small table boards | - |
| Smart Internet • Standard 。Optional - none | |
| Central control screen size (inches) | • 12.8 |
| Center console color screen resolution | 1728x1888 |
| Center console color screen pixel density (PPI) | • 200 |
| Touch screen vibration feedback | - |
| screen layout | Traditional dual-screen • layout |
| GPS navigation system | • Standard |
| AR real-world navigation | - |
| Navigation traffic information display | • Standard |
| roadside assistance service | • Standard icon |
| Bluetooth/Car Phone | • Standard |
| Mobile Internet Mapping | - |
| Internet of Vehicles | • Standard |
| 4G/5G network | • 5G |
| OTA upgrade | • Standard |
| face recognition | - |
| Fingerprint recognition | - |
| voiceprint recognition | - |
| emotion recognition | - |
| Voice recognition control | • Standard |
| system | |
| Voice free wake-up function | • Standard |
| • main driver | |
| Voice sub-area wake-up recognition function | • co-pilot |
| • second row | |
| Continuous Speech Recognition | • Standard |
| see can say | • Standard |
| voice assistant wake word | Hi NOMI |
| gesture control | - |
| Wi-Fi hotspot | • Standard |
| Media entertainment | |
| Multi-finger flying screen control | - |
| app Store | • Standard |
| multimedia interface | • USB/Type-C |
| Number of USB/Type-C | • 2 front row |
| ports | • 2 back row |
| USB/Type-C maximum charging power | - |
| Car TV | - |
| rear LCD screen | • Standard |
| simulated sound waves | - |
| audio brand | - |
| Number of speakers (units) | • twenty three |
| rear multimedia controls | - |
| lighting configuration • Standard 。Optional - none | |
| Low beam lights | • led |
| High beam | • led |
| daytime running lights | • Standard |
| Adaptive far and near light | • Standard |
| automatic headlights | • Standard |
| turn signal lamp | • Standard |
| Front fog lights | • Standard |
| Penetrating headlights | - |
| through tail lights | • Standard |
| Headlight Adaptive Steering (AFS) | - |
| headlight height adjustment | • Standard |
| headlight cleaning function | - |
| interior ambient light | • 256 colors |
| Active Ambient Mood Lighting | - |
| Lighting Features | geometric multiple • beam |
| Delayed headlight off | • Standard |
| Headlight rain and fog mode | - |
| glass/mirror • Standard | 。Optional - none |
| • front row | |
| electric windows | back row |
| One-button window lift: | whole car |
| Window anti-pinch function | Standard |
| electric icon adjustment | |
| heating | |
| electric folding | |
| Exterior mirror function | memory |
| Automatic downturn when reversing | |
| Automatic folding when locking the car | |
| Automatic anti-glare | |
| Interior rearview mirror function | Automatic anti-glare |
| vanity mirror | Main driving position + lighting |
| Passenger seat + lighting | |
| rear privacy glass | Standard |
| interior sunshade | |
| Rain Sensing Wipers | Standard |
| rear wiper | Standard |
| rear window open | - |
| Multi-layer soundproof glass | • whole car |
| Front windshield electric heating | - |
| heated water nozzle | - |
| air conditioner/refrigerator | |
| Air Conditioning Control Mode | automatic |
| Rear independent air conditioner | Standard |
| rear air outlet | Standard |
| Temperature zone control | Five-zone air conditioning |
| Car air purifier | Standard |
| In-car PM2.5 filter | Standard |
| HEPA filter | |
| negative ion generator | Standard |
| car fragrance device | Standard icon |
| car refrigerator | |
| Intelligent configuration | |
| Assisted driving operating system | NIO Pilot |
| Assisted driving chip | Four Nvidia Orin-X |
| Assisted Driving Chip Computing Power (TOPS) | 1,016 |
| Vehicle Intelligent System | Banyan |
| Vehicle Smart Chip | Qualcomm Snapdragon 8155 |
| In-vehicle system memory (GB) | 16 |
| In-vehicle system storage (GB) | 256 |
| digital key | |
| vehicle monitoring | |
| remote control | |
| Mobile App remote control | • charge management • service appointment |
| Smart car search • assistant | |
| heat pump management system | • Standard |
| Number of cameras outside the car (units) | • 11 |
| Number of cameras in the car (units) | • 1 |
| Ultrasonic radar quantity (unit) | • 12 |
| Number of millimeter wave radars (units) | • 5 |
| Number of lidars (units) | • 1 |
| Sub-meter high-precision positioning system | - |
| HD map | • Standard |
| Sentry (clairvoyance) mode | • Standard |
| V2X communication | • Standard |
| optional package • Standard 。Optional - none | |
| Customized options | Optional appearance, interior; wheels, brakes 3 optional packages |
| NAD Full Feature Service Subscription | Covering the automatic driving experience of some urban roads and closed expressways, it supports pilot parking, remote parking, smart call and other functional experiences, pilot assistance |
