| BASIC DATA | |||
| Make | Series Automobile | ||
| Model | Extended Range Max RWD Advanced Intelligent Driving | Extended Range Max RS 4WD Advanced Intelligent Driving | Pure Electric Max RWD Advanced Intelligent Driving |
| Car Type | Mid-size SUV | ||
| Pure electric cruising range (km) CLTC | 195km | 175km | 602km |
| Max Power | 200(272Ps) | 365(496Ps) | 200(272Ps) |
| Max Torque | 310N.m | ||
| Gearbox | Electric vehicle single-speed gearbox | ||
| Overalls | 4785x1930x1625 | ||
| Body Structure | 5-door 5-seater SUV | ||
| Max Speed | 200km/h | 210km/h | 200km/h |
| CAR BODY | |||
| Wheelbase | 2880mm | ||
| Seats | 5 | ||
| Luggage compartment volume (L) | 369-776 | 449-856 | |
| Curb Weight | 2220kg | 2335kg | 2235kg |
| Full Load Weight | 2595kg | 2710kg | 2610kg |
| Engine | |||
| Engine Model | H15RT | ||
| Displacement (mL) | 1499 | ||
| Air intake form | Turbocharger | ||
| Engine layout | Sideways | ||
| ELECTRIC MOTOR | |||
| Motor Description | Extended range 272 hp | Extended range 496 hp | Pure electric 272 hp |
| Motor Type | Permanent magnet/synchronous | AC/asynchronous at the front and permanent magnet/synchronous at the back | Permanent magnet/synchronous |
| Number of Drive Motors | Single Motor | Dual motors | Single Motor |
| Motor Layout | Rear | 4WD | Rear |
| CHASSIS | |||
| Drive | RR | Front + Rear | RR |
| Front Suspension | Double wishbone independent suspension | ||
| Rear Suspension | Multi-link independent suspension | ||
| CHARGING BATTERIES | |||
| Battery Type | Ternary lithium battery | ||
| Battery Brand | CALL | ||
| Charging batteries | Fast charge 0.5 hours Slow charge 5 hours | Fast charge 0.5 hours Slow charge 10.5 hours | |
| Battery capacity (kWh) | 42 | 83 | |
| WHEELS & BRAKE | |||
| Front Brake | Ventilated Disc | ||
| Rear Brake | Ventilated Disc | ||
| Parking Brake | Electronic parking | ||
| Front Tyres | 255/50 R19 | 255/45 R20 | 255/50 R19 |
| Rear Tyres | 255/50 R19 | 255/45 R20 | 255/50 R19 |
